Features :
| Model |
DH-30B |
DH-50B |
| Electric supply |
220-240V ~50Hz |
220-240V ~50Hz |
| Capacity |
30KW |
50KW |
| 105000 Btu/h |
150600 Btu/h |
| 25794 Kcal/h |
32990 Kcal/h |
| Motor power |
250 W |
250 W |
| Air Output |
720 m³/h |
1000 m³/h |
| Fuel consumption |
2.15 kg/h |
3.24 kg/h |
| Tank capacity |
56 L |
56 L |
| Product Meast |
1120*500*900mm |
1000*465*740mm |
| Packing Meast |
1120*500*900mm |
1000*465*740mm |
| N.W. |
48 kgs |
49 kgs |
| G.W. |
51.2 kgs |
52.2 kgs |
| Qty/20' |
74pcs |
74 pcs |
| Qty/40' |
164 pcs |
164 pcs |
| Qty/40'HQ |
192 pcs |
192 pcs |
Details:
1. Robust and tough design
2. Function on diesel oil or kerosene
3. Stainless steel combustion chamber with fan cooling
4. Durable external powder coating
5. With flame sensor
6. If no oil , heater will cut off the power
7. Fixed Oil display
8. Cut-off protection,re-pl ed in will not work automatically
9. Low pressure atomization,combustion completely
10. Easy maintenance
11. Ideal for heating warehouses, factories and workshops
12. Fully automatic operation controlled by PCB with room temperature stat
13. Waterproof class IPX4
14. Equipped with gear pump. It supply fuel more stable and long life
15. Can be used with flexible coated tubes
Certificates:
CE / LVD / EMC / RoHS approved
Introduction:
* Company history: established in 2021. professional manufacturer specialized in heaters.
* Industrial fan heater, industrial diesel heater, gas forced heater,radiator heater,quartz heater etc.
*Main markets: Germany, Denmark, Norway, Sweden, Finland, UK, France,Russia, Australia, America and Asia etc.
* Employees: 50-100
* Production capacity: 5 lines , 500,000 pcs/ year,
* Quality management system: ISO 9001, ISO 14001
Where to use
* Construction Sites * Factories * Barns
* Agriculture * Sports Events * Utility/Farm Buildings
Quality control system:
IQC (Incoming Quality Control)
IPQC (In Process Quality Control)
PQC (Process Quality Control)
FQC (Final Quality Control)
OQC (Out-going Quality Control)
